HW-1363 PXIe

● Compliant with PXIe/PXI bus standard specifications
● HW-1363(G3) and HW-1363(G2) are available for selection
● Built-in HOUWU® PXIe-9170 controller

HW-1363(G3)
● Built-in HOUWU® 3U 6-slot PXIe Gen3.0 high-speed backplane
● One 3U PXIe system slot and five 3U PXIe/PXI hybrid expansion slots
● System slot bandwidth 16GB/s
● Each expansion slot has a dedicated bandwidth 8GB/s

HW-1363(G2)
● Built-in HOUWU® 3U 6-slot PXIe backplane
● One 3U PXIe system slot and five 3U PXIe/PXI hybrid expansion slots
● System slot bandwidth 16GB/s

● Compatible with PXIe/PXI modules such as data acquisition, modular instruments, aviation bus, FPGA, etc.
● Built-in system status monitoring and management software HMCSP
● All aluminum-magnesium alloy reinforced compact design
● Special impact resistant corners and reinforced silicone handle design
● 13.3'' high-definition industrial display with 1920x1080 resolution
● Multi-point capacitive touch screen or resistive touch screen
● Industrial touch pad and waterproof silicone keyboard
● Built in 300W high-quality industrial power supply (600W optional)
● 9V~36V DC power supply wide voltage input (Support 28V aviation power supply)
● Power input with aviation connector design
● PXIe cage retracted 45mm design
● Flexibly customizable IO interface with aviation connector

The industry's first high-performance 3U 6-slot PXIe ruggedized notebook

HW-1363 is the industry's first 13.3'' PXIe ruggedized notebook with built-in Intel^® Core^TM 6^th or 9^th or 11^th Gen i7 Quad-core eight-thread, six-core twelve-thread, or eight-core sixteen-thread CPU, embedded PXIe controller, PXIe backplane, high-definition industrial display and ruggedized chassis. This PXIe notebook adopts professional industrial appearance design, all aluminum-magnesium alloy structure reinforced compact design, integrated 13.3'' high-definition industrial display,multi-point capacitive touch screen or resistive touch screen, industrial touch pad and waterproof silicone keyboard, etc. It has the characteristics of high integration, robustness, portability, and is suitable for various harsh indoor and outdoor environments or complex working conditions where test equipment needs to be portable and mobile.

HW-1363(G3)
Built in high-performance HOUWU^® 3U 6-slot PXIe high-speed backplane, based on PCIe Gen3.0 technology, in compliant with PXIe/PXI bus standard specifications, with one 3U PXIe system slot and five 3U PXIe/PXI hybrid expansion slots (compatible with PXIe and PXI modules).The system slot bandwidth is16GB/s, each expansion slot has a dedicated bandwidth 8GB/s.

HW-1363(G2)

Built in high-performance HOUWU^® 3U 6-slot PXIe backplane, based on PCIe Gen2.0 technology, in compliant with PXIe/PXI bus standard specifications, with one 3U PXIe system slot and five 3U PXIe/PXI hybrid expansion slots (compatible with PXIe and PXI modules), slot 2 bandwidth 4GB/s, slot 3 bandwidth 4GB/s, slot 4 bandwidth 4GB/s, slot 5 bandwidth 2GB/s, slot 6 bandwidth 2GB/s, resulting in a total system slot bandwidth 16GB/s.

HW-1363 is compatible with PXIe/PXI modules such as high-speed data acquisition, high-speed digitizer, digital multimeter, aviation bus, FPGA, RF and switch modules. The machine has built-in system status monitoring and management software HMCSP, which can monitor the voltage of each power supply, chassis internal temperature and fan speed in real time, and supports PWM fan speed control. According to the high and low temperature inside the chassis, the fan speed is adaptively adjusted to dissipate heat for the controller and modules.

HW-1363 makes full use of the characteristics of PXIe/PXI bus, such as stability, reliability, good compatibility, solid structure, large data throughput, high performance. According to the different project applications, this PXIe notebook can be built with various PXIe/PXI modules to realize the test and measurement of microwave, radio frequency, high-speed digital, signal simulation, prototype validation, voltage, current, temperature, frequency, stress, strain, vibration, shock, audio, video and various aviation bus, etc. Users can quickly build various measurement, test and control system on this portable measurement & control platform, which is suitable for military defense, aerospace, weapons, electronics, ships and other field actual combat applications and scientific experimental research occasions.

Operating System	Windows^®7 (Option 1, Option 2) Windows^®10 (Option 1, Option 2, Option 3, Option 4, Option 5)
CPU	Intel^® Core^TM6^th Gen i7-6822EQ 2.0GHz (8MB Cache, up to 2.8GHz) Quad-Core, Eight-Thread (Option 1) Intel^®Core^TM6^th Gen i7-6820EQ 2.8GHz (8MB Cache, up to 3.5GHz) Quad-Core, Eight-Thread (Option 2) Intel^®Core^TM9^th Gen i7-9850HL 1.9GHz (9MB Cache, up to 4.1GHz) Six-Core, Twelve-Thread (Option 3) Intel^® Core^TM 9^th Gen i7-9850HE 2.7GHz (9MB Cache, up to 4.4GHz) Six-Core, Twelve-Thread (Option 4) Intel^® Core^TM 11^th Gen i7-11850HE 2.6GHz (24MB Cache, up to 4.7GHz) Octa-Core Sixteen-Thread (Option 5)
RAM	16GB DDR4 (upgradeable to 32GB/64GB)
Storage	Original dual solid state drive SSD design: 1, NVMe 500GB SSD x1 (system disk) (upgradeable to 1TB/2TB/4TB) 2, 2.5'' SATA3.0 1TB SSD x1 (data disk) (upgradeable to 2TB/4TB/8TB)
Link Configuration	HW-1363(G3) with PXIe-9170 Controller PCIe Gen3.0 Specification 2 Link: PCIe3.0 x8 + PCIe3.0 x8 HW-1363(G2) with PXIe-9170 Controller PCIe Gen3.0 Specification 4 Link: 4 x PCIe3.0 x4
LCD	13.3'' high-definition industrial display with 1920x1080 resolution
Touch Screen	Multi-point capacitive touch screen / Industrial resistive touch screen (optional)
Backplane	HW-1363(G3) 3U 6-slot PXIe backplane based on PCIe Gen3.0 technology 1 PXIe system slot and 5 PXIe/PXI hybrid expansion slots System slot bandwidth 16GB/s, each expansion slot has a dedicated bandwidth 8GB/s HW-1363(G2) 3U 6-slot PXIe backplane based on PCIe Gen2.0 technology 1 PXIe system slot and 5 PXIe/PXI hybrid expansion slots System slot bandwidth 16GB/s, slot 2 bandwidth 4GB/s, slot 3 bandwidth 4GB/s, slot 4 bandwidth 4GB/s, slot 5 bandwidth 2GB/s, slot 6 bandwidth 2GB/s
IO	LAN x2, USB3.0 x4, USB2.0 x2, RS232 x1, DP x2, VGA x1, SMB x1, RESET x1, LED x4 PXIe cage retracts 45mm and the aviation connector IO adapter panel area is 285mm x 86mm.
Keyboard	Waterproof silicone keyboard
Aviation Connector	Users can flexibly customize IO interfaces with aviation connectors for PXIe/PXI modules
Heat Dissipation	The fan supports PWM operation mode, adaptive speed regulation, active heat dissipation, and complies with PXIe/PXI bus standard specifications.
Power Supply	Default Power: 9V~36V DC wide voltage input, aviation connector design With dedicatedpower adapter: Input AC 100V~240V, Out put DC 24V Rated load power 300W Optional Power: AC voltageinput, 85V~264V, aviation connector design For high-power RF and microwave application Rated load power 600W
Environment	Operating temperature: 0°C ~ 50°C (normal level) Operating temperature: -10°C ~ 55°C (industrial level) Storage temperature: -40°C ~ 70°C Relative humidity: 5% ~ 95% (no condensation)
Shock Resistance	30G peak, half-sine, 11ms pulse
Vibration Resistance	2.4Grms@5~500Hz (1 hour each in X, Y, Z directions)
Dimension	376 x 316 x 136 mm(excluding corners and handles)
Weight	HW-1363(G3) 11.6KG (including HOUWU^® PXIe-9170 controller) HW-1363(G2) 11.4KG (including HOUWU^® PXIe-9170 controller)
Packaging	Customized aviation trolley case
Category	nMCS, notebook PXIe Measurement & Control System
