HW-1693BAT Portable
● Built-in ultra-long-life smart lithium battery
● Optional high-capacity external smart lithium battery to realize long-term operation of equipment
● Compliant with PXIe/PXI bus standard specifications
● HW-1693BAT(G3) and HW-1693BAT(G2) are available for selection
HW-1693BAT(G3)
● Built-in HOUWU® PXIe-9180 controller
● Built-in HOUWU® 3U 9-slot PXIe Gen3.0 high-speed backplane
● One 3U PXIe system slot
● Seven 3U PXIe/PXI hybrid expansion slots and one 3U PXIe timing slot
● System slot bandwidth 24GB/s
● Each expansion slot has a dedicated bandwidth 8GB/s
HW-1693BAT(G2)
● Built-in HOUWU® PXIe-9170 controller
● Built-in HOUWU® 3U 9-slot PXIe backplane
● One 3U PXIe system slot and eight 3U PXIe/PXI hybrid expansion slots
● System slot bandwidth 8GB/s
● Three 4GB/s expansion slots and five 2GB/s expansion slots
● Compatible with PXIe/PXI modules such as data acquisition, modular instruments, aviation bus, FPGA, etc.
● Built-in system status monitoring and management software HMCSP
● Built-in smart lithium battery monitoring and management software HBSSM
● All aluminum magnesium alloy reinforced compact design
● Special impact resistant corners and reinforced silicone handle design
● 15.6'' high-definition industrial display with 1920x1080 resolution
● Industrial resistive touch screen, industrial touch pad and waterproof silicone keyboard
● 9V~32V DC power supply wide voltage input (with dedicated 24V power adapter)
● Power input with aviation connector design
● PXIe cage retracted 140mm design
● Flexibly customizable IO interface with aviation connector
● Optional high-capacity external smart lithium battery to realize long-term operation of equipment
● Compliant with PXIe/PXI bus standard specifications
● HW-1693BAT(G3) and HW-1693BAT(G2) are available for selection
HW-1693BAT(G3)
● Built-in HOUWU® PXIe-9180 controller
● Built-in HOUWU® 3U 9-slot PXIe Gen3.0 high-speed backplane
● One 3U PXIe system slot
● Seven 3U PXIe/PXI hybrid expansion slots and one 3U PXIe timing slot
● System slot bandwidth 24GB/s
● Each expansion slot has a dedicated bandwidth 8GB/s
HW-1693BAT(G2)
● Built-in HOUWU® PXIe-9170 controller
● Built-in HOUWU® 3U 9-slot PXIe backplane
● One 3U PXIe system slot and eight 3U PXIe/PXI hybrid expansion slots
● System slot bandwidth 8GB/s
● Three 4GB/s expansion slots and five 2GB/s expansion slots
● Compatible with PXIe/PXI modules such as data acquisition, modular instruments, aviation bus, FPGA, etc.
● Built-in system status monitoring and management software HMCSP
● Built-in smart lithium battery monitoring and management software HBSSM
● All aluminum magnesium alloy reinforced compact design
● Special impact resistant corners and reinforced silicone handle design
● 15.6'' high-definition industrial display with 1920x1080 resolution
● Industrial resistive touch screen, industrial touch pad and waterproof silicone keyboard
● 9V~32V DC power supply wide voltage input (with dedicated 24V power adapter)
● Power input with aviation connector design
● PXIe cage retracted 140mm design
● Flexibly customizable IO interface with aviation connector
The industry's first high-performance 15.6'' built-in smart lithium battery 3U 9-slot PXIe ruggedized portable
HW-1693BAT is the industry's first 15.6'' ruggedized portable with built-in embedded PXIe controller, PXIe backplane, smart lithium battery, high-definition industrial display and ruggedized chassis.This platform adopts professional industrial appearance design, all aluminum-magnesium alloy structure reinforced compact design, integrated 15.6'' high-definition industrial display, industrial resistive touch screen, industrial touch pad, waterproof silicone keyboard and smart lithium battery,etc. It has the characteristics of high integration, robustness, portability, and is suitable for various harsh indoor and outdoor environments or complex working conditions where test equipment needs to be portable and mobile.HW-1693BAT(G3)
Built-in HOUWU® Intel® CoreTM 6th or 9th or 11th Gen i7 Quad-core eight-thread or six-core twelve-thread or eight-core sixteen-thread CPU embedded PXIe controller, 3U 9-slot PXIe backplane, based on PCIe Gen3.0 technology,in compliant with PXIe/PXI bus standard specifications, with one PXIe system slot, seven PXIe/PXI hybrid expansion slots (compatible with PXIe and PXI modules) and one PXIe timing slot. The system slot bandwidth is 24GB/s, each expansion slot has a dedicated bandwith 8GB/s.
HW-1693BAT(G2)
Built-in HOUWU® Intel® CoreTM 6th or 9th or 11th Gen i7 Quad-core eight-thread CPU embedded PXIe controller, 3U 9-slot PXIe backplane, based on PCIe Gen2.0 technology, compliant with PXIe/PXI bus standard specification, with one PXIe system slot and eight PXIe/PXI hybrid expansion slots (compatible with PXIe and PXI modules). The system slot bandwidth is 8GB/s, providing three dedicated 4GB/s bandwidth PXIe/PXI hybrid expansion slots and five dedicated 2GB/s bandwidth PXIe/PXI hybrid expansion slots.
HW-1693BAT is compatible with PXIe/PXI modules such as high-speed data acquisition, high-speed digitizer, digital multimeter, aviation bus, FPGA, RF and switch modules. The machine has built-in system status monitoring and management software, HMCSP,which can monitor the voltage of each power supply,chassis internal temperature and fan speed in real time,and supports PWM fan speed control, According to the high and low temperature inside the chassis, the fan speed is adaptively adjusted to dissipate heat for the controller and modules. The machine has built-in smart lithium battery monitoring and management software HBSSM, which can monitor all status parameters of the smart lithium battery in real time, including battery voltage, charging and discharging current, real-time power, battery life, charging and discharging times, etc.
HW-1693BAT makes full use of the characteristics of PXIe/PXI bus,such as stability, reliability, good compatibility, solid structure, large data throughput, high performance. According to the different project applications,this PXIe portable can be built with various PXIe/PXI modules to realize the test and measurement of microwave ,radio frequency, high-speed digital, signal simulation, prototype verification, voltage,current, temperature,frequency, stress,strain, vibration,shock,audio,video and various aviation bus,etc.Users can quickly build various measurement, test and control system on this portable measurement & control platform, which is suitable for military defense, aerospace, weapons,electronics, ships and other field actual combat applications and scientific experimental research occasions.
